Technical Data

MZF-T06-td

Technical Information

Technical Information
Flowrate 1 to 30 LPM
Medium Oil and Emulsion
PH 6.5 until 9.5
Temperature 60° C
Quality of cleanliness Down to 5 ym
Material Housing Steel / Stainless Steel
Material Rotor Aluminium
Rotor capacity 5.2 dm3
Sludge Volume 2 to 3 kg
Type of cleaning 2 phase
Rotor Speed 50 Hz = 2850 RPM
60 Hz = 3400 RPM
Separating Factor 900 g to 1180 g (1 g = gravity acceleration)
Noise emission < 70 dBa
Drive Directdrive
Drive Power 0.8 kW
Solids discharge Manual
Liquid return In free descent
Controlpanel Including
Inlet > 585 mm
Dimension > 640 x 450 x 585 mm
Weight > 75 kg
Options Clean Liquid Tank
Pumps
Chiller
